Fully Automatic Box Sealing and Banding Machine - Tuva Pack | Packaging Machines and Robotic Systems

Fully Automatic Box Sealing and Banding Machine

Fully Automatic Box Sealing and Banding Machine
Fully Automatic Box Sealing and Banding Machine
Model: ACS5050
Fully Automatic Box Sealing Machine; It closes the top covers of your filled parcels without touching the hand and makes the banding. The machine works continuously in a ready state. By making your packing process easier, it increases your capacity and reduces your cost.
  • Automatic control with relay
  • Capacity: 20 boxes / min. (According to box size)
  • It adapts to your parcels of different sizes thanks to its mechanism with 2 adjustment levers.
  • Package tape mechanism: 3 cm
  • Door and safety switch sensors for occupational safety in machines
  • Dimensions of the machine: L 1800 mm | W 900mm | H 1500 mm
  • Weight: 280 kg
  • Required air pressure: 5 - 6 bar
  • Electricity: 220 V. 50-60 Hz. 1 Ph.
  • Power: 0.30 kW
  • The machine is installed on site by our assembly team, given working training and delivered with usage and maintenance instructions.
  • Machines - 2 YEARS - guaranteed.
  • Production from static painted or completely chromed stainless steel
  • Large, standard and small machine options; The standard manufacturing dimensions of the machine can also be changed according to the dimensions of the boxes you will work with, and a more harmonious operation is provided for the products.
  • Pass gluing system: Hot Melt system
  • Bottom caps banding mechanism (2 pieces of banding mechanism top and bottom)
  • Automatic box size adjustment system; With servo motors and recipe registration system, automatic and fast transition to different size box settings is provided with a single click.
  • Mixed parcel making feature; It provides fast positioning according to the dimensions of the box, thanks to special sensors and servo motors, according to mixed boxes of different sizes.
